| 分類 | 型號 | 尺寸 | 視域 | 引腳數 | 備注參數 |
| 802 | LCM0802A/B | 58.0*32.0*13.5 | 38.0*16.0 | 16 | A為單邊14腳，B為單邊16腳，全部為 側背光 |
| LCM0802C | 40.0*35.2*7.8 | 30.5*14.0 | |||
| 1601 | LCM1601A | 80.0*36.0*11.3 | 64.5*14.5 | 側背光 | |
| LCM1601B | 122.0*33.0*13.3 | 99.0*13.0 | |||
| 1602 | LCM1602C | 80.0*36.0*11.8 | 64.3*16.0 | 側背光 | |
| LCM1602D | 80.0*36.0*11.8 | 64.3*16.0 | |||
| LCM1602B | 122.0*44.0*13.5 | 99*24 | |||
| LCM1602H | 85.0*30.0*13 | 64.3*16.0 | |||
| LCM1602E | 84.0*44.0*11.8 | 64.3*16.0 | |||
| LCM1602F | 85.0*36.0*12.3 | 64.3*16.0 | |||
| 1604 | LCM1604B | 87.0*60.0*13.0 | 62.0*26.0 | 側背光 | |
| 2002 | LCM2002A | 116.0*37.0*13.2 | 85.0*18.6 | A為側背光，B為底 背光（B只生產黃 | |
| LCM2002B | 180.0*40.0*13.8 | 149.0*23.0 | |||
| 2004 | LCM2004A/B | 98.0*60.0*13.2 | 77.0*25.2 | 側背光，B鐵框尺寸 小于A，其他參數一 | |
| 4002 | LCM4002A | 182.0*33.5*14.0 | 154.4*16.5 | 底背光，生產黃綠 | |
| 4004 | LCM4004B | 190.0*54.0*13.3 | 149.0*30.0 | 底背光，生產黃綠 | |
| 12232 | LCM12232A | 68.6*27.5*7.4 | 61.0*18.0 | 18 | 全部側背光， ST7920芯片為帶中文字庫 |
| LCM12232B | 84.0*44.0*12.8 | 60.0*18.0 | |||
| LCM12232C | 76.4*29.1*7.3 | 61.0*18.0 | |||
| LCM12232D | 74.0*40.0*8.6 | 60.0*18.0 | 9 | ||
| LCM12232F | 84.0*44.0*13.5 | 60.0*18.0 | 24 | ||
| LCM12232J | 66.3*27.5*8.5 | 54.8*18.3 | 8 | ||
| 128*32 | LCM12832A | 84.0*44.0*14.1 | 70.0*20.0 | 18 | |
| 12864 | LCM12864A | 113.0*65.0*12.9 | 73.4*38.8 | 20 | 全部側背光， ST7920芯片為帶中文字庫 |
| LCM12864C | 78.0*70.0*12.0 | 62.0*44.0 | |||
| LCM12864D | 106.0*69.0*12.3 | 62.0*44.0 | |||
| LCM12864E | 73.2*60.0*9.3 | 62.0*40.0 | |||
| LCM12864F | 78.0*70.0*12.3 | 62.0*44.0 | |||
| LCM12864I | 54.0*50.0*7.7 | 43.5*28.8 | |||
| LCM12864J-1 | 93.0*70.0*13.5 | 70.7*38.8 | |||
| LCM12864J-2 | 93.0*70.0*13.5 | 70.7*38.8 | 22 | ||
| LCM12864M/M-3 | 93.0*70.0*12.5 | 72.0*40.0 | 20 | ||
| LCM12864S | 78.0*70.0*12.3 | 62.0*44.0 | |||
| LCM12864A-18 | 75.0*55.0*9.5 | 60.0*32.5 | |||
| 19264 | LCM19264A-1 | 130.0*65.0*12.8 | 104.0*39.0 | 20 | 全部側背光， ST7920芯片為帶中文字庫 |
| LCM19264B | 120.0*62.0*12.5 | 100.0*37.0 | |||
| LCM19264C | 130.0*53.0*12.8 | 104.0*39.0 | |||
| LCM19264T | 100.0*60.0*11.3 | 84.0*31.0 | |||
| 16032 | LCM16032D | 116.0*35.0*11.8 | 83.0*18.5 | ||
| 16064 | LCM16064A | 98.0*60.0*14.0 | 77.0*26.0 | ||
| 160128 | LCM160128A | 129.0*102.0*11.8 | 101.0*82.0 | 22 | 側背光，綁定芯片 |
| LCM160128A-1 | 129.0*102.0*16.5 | 101.0*82.0 | |||
| 24064 | LCM24064B | 180.0*65.0*14.5 | 132.0*39.0 | 側背光 | |
| 240128 | LCM240128A | 144.0*104.0*12.0 | 114.0*64.0 | 貼片芯片 | |
| LCM240128B | 144.0*104.0*12.0 | 114.0*64.0 | 綁定芯片 | ||
| LCM240128E | 154.0*84.0*12.3 | 114.0*64.0 | |||
| 320240 | LCM320240B | 160.0x109.0x13.5 | 121.0x93.0 | LED | |
| LCM320240C | 139.0x100.0x12.5 | 103.0x79.0 | LED |
